- McKechnie® is the only NZ Aluminium extruder to achieve third-party CEMARS® product certification by Enviro-Mark Solutions Ltd. You can specify and use McKechnie® Aluminium extrusion knowing it is the best choice for you, your customer and the environment.
- Anodized aluminum T-Track features rounded top edges for protection and impact resistance. Drilled and tapped holes at ends make endstop installation easy. 32 mm high-performance track is black hardcoat-anodized. It has precise 33 mm pinstop hole spacing. Stainless steel track is available in 32 and 40 mm.
- T-slot Nuts can be inserted into the aluminium profile groove. T-slot nuts are useful for securing components onto aluminium profiles, as well as joining two profiles together, by creating a clamping force for a screw in the groove. M3, M4, M5, M6 and M8 screws can be used depending on which T-slot Nut you choose.
Note: Red Indicates – MILL RUN ONLY, Non-Stocked Item. MINIMUM ORDER QUANTITY 200kg. Contact your local branch to enquire.
If you’re still in two minds about t slot aluminium and are thinking about choosing a similar product, AliExpress is a great place to compare prices and sellers. We’ll help you to work out whether it’s worth paying extra for a high-end version or whether you’re getting just as good a deal by getting the cheaper item.
Search - dies, products and topics...You can search for die numbers, product names and topics e.g. cladding
NEW ZEALAND
Aluminum T Slot Nz Cars
Download PDFClick on a column heading to sort by that column
| Extrusion | DIE No. | Dimensions | Type | Drawing | W | P | Ix | Iy | Mi |
|---|---|---|---|---|---|---|---|---|---|
| SLIDING DOOR TRACK | UA1341 | 12.00 x 7.00 | Miscellaneous | 0.083 | 36.00 | 129.53 | 181.74 | 3112.70 | |
| PICTURE FRAME | UA2039 | 12.50 x 20.50 | Miscellaneous | 0.163 | 102.00 | 2912.90 | 1035.29 | 39481.90 | |
| PICTURE FRAME | UA2000 | 13.10 x 16.30 | Miscellaneous | 0.144 | 86.00 | 1722.00 | 811.32 | 25333.20 | |
| TRACK TOP FIX | UA1350 | 14.50 x 5.80 | Miscellaneous | 0.082 | 54.00 | 93.57 | 526.81 | 6203.80 | |
| 6MM GLASS JOINTER | UA1356 | 16.00 x 10.50 | Miscellaneous | 0.159 | 82.00 | 1022.15 | 1016.38 | 20385.30 | |
| TRACK SIDE FIX | UA1351 | 17.00 x 12.00 | Miscellaneous | 0.125 | 80.00 | 250.98 | 1674.93 | 19259.10 | |
| 16MM DRAWER PULL | UA1643 | 17.40 x 44.00 | Miscellaneous | 0.546 | 164.00 | 40536.09 | 5446.13 | 459822.20 | |
| GLASS CHANNEL | UA4130 | 18.00 x 17.99 | Miscellaneous | 0.165 | 104.00 | 2111.17 | 3332.14 | 54433.10 | |
| 16MM CUPBOARD PULL | UA1363 | 18.00 x 34.00 | Miscellaneous | 0.314 | 129.00 | 10150.40 | 2873.42 | 130238.20 | |
| DOOR TRACK | UA2154 | 19.00 x 6.00 | Miscellaneous | 0.142 | 47.00 | 118.84 | 1135.07 | 12539.10 | |
| DOOR TEE | UA1345 | 19.00 x 15.80 | Miscellaneous | 0.146 | 65.00 | 547.28 | 1280.11 | 18273.90 | |
| TRACK | UA3703 | 19.10 x 9.30 | Miscellaneous | 0.116 | 80.00 | 425.15 | 2189.25 | 26144.00 | |
| COLONIAL BEAD | UA1952 | 19.20 x 3.80 | Miscellaneous | 0.121 | 57.00 | 34.65 | 1603.11 | 16377.60 | |
| COLONIAL BEAD | UA1951 | 19.20 x 10.00 | Miscellaneous | 0.174 | 83.00 | 545.90 | 1513.97 | 20598.70 | |
| 19MM DRAWER PULL | UA1950 | 19.50 x 44.00 | Miscellaneous | 0.633 | 165.00 | 39347.19 | 7446.95 | 467941.40 | |
| SLIDING DOOR TEE | UA1343 | 20.30 x 13.50 | Miscellaneous | 0.172 | 66.00 | 1098.82 | 993.95 | 20927.70 | |
| 19MM TICKET HOLDER | UA1347 | 21.00 x 3.00 | Miscellaneous | 0.069 | 53.00 | 11.62 | 1161.73 | 11733.50 | |
| PICTURE FRAME | UA1359 | 22.02 x 22.95 | Miscellaneous | 0.281 | 139.00 | 3241.39 | 5756.13 | 89975.20 | |
| 6MM GLASS TRACK BASE | UA1354 | 23.00 x 8.00 | Miscellaneous | 0.178 | 98.00 | 357.55 | 3835.98 | 41935.30 | |
| CUSTOMWOOD INSERT | UA2516 | 23.00 x 12.00 | Miscellaneous | 0.165 | 104.00 | 755.64 | 3174.03 | 39296.70 | |
| 6MM GLASS TRACK TOP | UA1353 | 23.00 x 14.00 | Miscellaneous | 0.232 | 131.00 | 1937.48 | 5492.74 | 74302.20 | |
| AWNING FRAME | UA3006 | 23.00 x 23.00 | Miscellaneous | 0.381 | 126.00 | 7902.33 | 10598.94 | 185012.70 | |
| 7.9MM F - SECTION | UA1663 | 23.80 x 15.00 | Miscellaneous | 0.301 | 100.00 | 1855.41 | 5325.58 | 71809.90 | |
| 22MM TICKET HOLDER | UA2483 | 25.00 x 4.70 | Miscellaneous | 0.110 | 70.00 | 67.76 | 3029.19 | 30969.50 | |
| MIRROR MOUNT BASE | UA6861 | 25.00 x 10.50 | Miscellaneous | 0.218 | 115.00 | 1203.76 | 4767.44 | 59712.00 | |
| DOOR TRACK | UA2229 | 25.00 x 22.88 | Miscellaneous | 0.240 | 95.00 | 5277.14 | 2102.60 | 73797.40 | |
| SLIDING DOOR TEE | UA3769 | 25.40 x 15.90 | Miscellaneous | 0.364 | 80.00 | 2785.75 | 4190.28 | 69760.30 | |
| SHOWERSCREEN FRAME | UA1392 | 25.50 x 25.50 | Miscellaneous | 0.428 | 135.00 | 14069.83 | 11314.67 | 253845.00 | |
| MIRROR MOUNT TOP | UA6862 | 27.03 x 12.30 | Miscellaneous | 0.166 | 82.00 | 470.15 | 5598.60 | 60687.50 | |
| DOOR TRACK | UA2221 | 30.00 x 25.00 | Miscellaneous | 0.378 | 177.00 | 11488.83 | 19451.37 | 309402.00 | |
| HANGING FILE RAIL | UA3266 | 30.00 x 32.00 | Miscellaneous | 0.389 | 187.00 | 9167.11 | 19739.70 | 289068.10 | |
| SHOWERSCREEN FRAME | UA1391 | 30.50 x 10.50 | Miscellaneous | 0.338 | 107.00 | 2042.59 | 10400.85 | 124434.40 | |
| 29MM TICKET HOLDER | UA1348 | 32.00 x 3.00 | Miscellaneous | 0.115 | 76.00 | 18.79 | 4482.45 | 45012.40 | |
| 6MM GLASS SILL | UA1352 | 32.00 x 9.50 | Miscellaneous | 0.182 | 98.00 | 466.88 | 4215.26 | 46821.40 | |
| SLATWALL INSERT | UA2852 | 32.00 x 12.50 | Miscellaneous | 0.223 | 140.00 | 1026.35 | 8295.22 | 93215.70 | |
| DIN RAIL | UA7713 | 35.20 x 13.10 | Miscellaneous | 0.381 | 140.00 | 2522.68 | 17983.67 | 205063.50 | |
| STAKE ANGLE FITS 1391 | UA1390 | 35.25 x 35.25 | Miscellaneous | 1.296 | 228.00 | 33708.58 | 55162.02 | 888706.00 | |
| DIN RAIL | UA2906 | 35.50 x 13.00 | Miscellaneous | 0.352 | 141.00 | 2448.12 | 18881.91 | 213300.30 | |
| FLASHING | UA2086 | 37.36 x 40.04 | Miscellaneous | 0.224 | 141.00 | 20303.94 | 1884.03 | 221879.70 | |
| 35MM TICKET HOLDER | UA2482 | 38.20 x 4.70 | Miscellaneous | 0.153 | 97.00 | 75.07 | 9172.83 | 92479.00 | |
| CAPPING | UA3219 | 39.00 x 47.30 | Miscellaneous | 0.762 | 285.00 | 63707.83 | 76739.34 | 1404471.70 | |
| BLIND ROLLER | UA3267 | 40.70 x 40.35 | Miscellaneous | 0.564 | 155.00 | 38837.72 | 37882.12 | 767198.40 | |
| DROP SIDE HINGE | UA7237 | 47.50 x 12.00 | Miscellaneous | 0.507 | 127.00 | 1888.90 | 23652.88 | 255417.80 | |
| 50MM TICKET HOLDER | UA2462 | 48.00 x 52.00 | Miscellaneous | 0.762 | 265.00 | 14062.09 | 107145.64 | 1212077.30 | |
| HINGE | UA1369 | 49.25 x 14.50 | Miscellaneous | 0.588 | 114.00 | 2064.19 | 45221.04 | 472852.30 | |
| HINGE | UA1370 | 49.25 x 14.50 | Miscellaneous | 0.607 | 118.00 | 2603.47 | 46531.80 | 491352.70 | |
| 6MM SHELF BRACKET | UA1679 | 50.00 x 35.00 | Miscellaneous | 0.505 | 196.00 | 7110.23 | 46566.62 | 536768.50 | |
| WORKSPACE POST | UA2163 | 51.00 x 45.00 | Miscellaneous | 2.309 | 462.00 | 158267.18 | 196807.70 | 3550748.80 | |
| 51MM FLUTED COLUMN | UA2251 | 51.00 x 51.00 | Miscellaneous | 0.622 | 158.00 | 60327.65 | 60327.65 | 1206553.00 | |
| 3MM SPLIT TEE | UA1342 | 57.00 x 32.00 | Miscellaneous | 1.035 | 226.00 | 37142.34 | 46424.08 | 835664.20 | |
| 4MM SPLIT TEE | UA3016 | 57.00 x 32.00 | Miscellaneous | 1.035 | 226.00 | 37142.34 | 47065.46 | 842078.00 | |
| 57 X 50 X 3 CHANNEL | UA7774 | 57.00 x 50.00 | Miscellaneous | 1.206 | 304.00 | 112253.20 | 247325.75 | 3595789.50 | |
| BULB TEE | UA7071 | 60.00 x 35.00 | Miscellaneous | 1.086 | 185.00 | 17779.97 | 161765.83 | 1795458.00 | |
| 16MM SHELF BRACKET | UA1678 | 60.00 x 50.00 | Miscellaneous | 0.859 | 250.00 | 61483.61 | 45640.35 | 1071239.60 | |
| 17MM SHELF BRACKET MELTECA | UA2589 | 61.00 x 50.00 | Miscellaneous | 0.861 | 252.00 | 61027.67 | 48140.78 | 1091684.50 | |
| SCALLOP MOULD | UA1492 | 63.50 x 6.35 | Miscellaneous | 0.727 | 130.00 | 615.11 | 67776.33 | 683914.40 | |
| LT7 DOOR CAP | UA1340 | 65.50 x 43.00 | Miscellaneous | 0.508 | 253.00 | 28997.31 | 99853.90 | 1288512.10 | |
| BULB TEE | UA7070 | 70.00 x 40.00 | Miscellaneous | 1.447 | 214.00 | 31734.98 | 286758.96 | 3184939.40 | |
| CONCRETE SCREED | UA4382 | 70.00 x 50.00 | Miscellaneous | 1.234 | 235.00 | 189327.10 | 319026.90 | 5083540.00 | |
| P - SECTION | UA4980 | 76.00 x 38.00 | Miscellaneous | 0.793 | 227.00 | 52801.49 | 143053.76 | 1958552.50 | |
| 80 X 40 X 2.5 RHS WITH SCREW FLUTES | UA7788 | 80.00 x 40.00 | Miscellaneous | 2.134 | 239.00 | 176977.26 | 649554.22 | 8265314.80 | |
| DROP SIDE HINGE | UA5402 | 90.00 x 28.00 | Miscellaneous | 1.828 | 221.00 | 29001.68 | 477316.90 | 5063185.80 | |
| OFFSET TEE | UA6341 | 100.00 x 56.00 | Miscellaneous | 2.429 | 310.00 | 188885.25 | 612351.35 | 8012366.00 | |
| PLANK - DECK EXTENSION | UA2899 | 123.20 x 50.00 | Miscellaneous | 2.032 | 418.00 | 260569.05 | 1218732.32 | 14793013.70 | |
| TOE BOARD | UA3465 | 150.00 x 13.00 | Miscellaneous | 1.823 | 350.00 | 10804.24 | 1325454.18 | 13362584.20 | |
| 200 X 50 X 2.5 RHS WITH SCREW FLUTES | UA7773 | 200.00 x 50.00 | Miscellaneous | 3.612 | 498.00 | 647349.72 | 6063908.67 | 67112583.90 | |
| FISH BOARD | UA4050 | 203.20 x 22.30 | Miscellaneous | 2.688 | 599.00 | 55845.93 | 4322679.90 | 43785258.30 | |
| PLANK | UA4592 | 228.00 x 50.00 | Miscellaneous | 3.447 | 657.00 | 493421.57 | 6814914.49 | 73083360.60 | |
| BENCH SEAT TOP | UA4473 | 254.00 x 54.98 | Miscellaneous | 2.787 | 870.00 | 394193.40 | 8214824.05 | 86090174.50 |
Extruded Aluminum T-slot Nz
Diagrams actual size unless otherwise indicated. Diagrams are schematic only and are not intended as specification drawings.
OAD = Overall dimensions (mm)
P = External periphery (mm)
R = Radiused corner (mm)
W = Weight (kg/m)
Polar MI units mm4
Ix & Iy units mm4
